Mobile Base (No Concrete)

8x40 Tornado Shelter – Mobile Base (No Concrete)

The CSB4008 is an above-ground steel tornado shelter (8' x 40') for up to 106 persons Maximum Occupancy (64 at design occupancy), on its own steel Mobile Base — no concrete to pour, and it relocates with your project. It has two storm-rated doors and 320 sq ft of protected floor area. Designed to FEMA P-361 and ICC 500 criteria for EF-5 tornadoes (250 mph winds).

Maximum Occupancy
Up to 106 persons
Footprint
8' x 40' · 320 sq ft
Storm-rated doors
2
Wind rating
EF-5 · 250 mph

Also available as a Concrete Slab Install (CS4008).

CSB4008 specifications

ModelCSB4008
Footprint8' x 40'
Protected floor area320 sq ft
Maximum OccupancyUp to 106 persons (3 sq ft / person)
Design occupancy64 persons (5 sq ft / person)
Storm-rated doors2
Install typeMobile Base (No Concrete)
Wind ratingEF-5 tornado, 250 mph
StandardsDesigned to FEMA P-361 and ICC 500 criteria
ConstructionSolid-welded steel

Mobile Base (No Concrete)

  • Sits on its own steel base — no concrete to pour.
  • Relocates with your project: job sites, turnarounds, seasonal and temporary workforces.
  • Faster site prep and flexible rental terms.

Designed to FEMA P-361 and ICC 500 criteria for EF-5 tornadoes (250 mph winds).

Full engineering details, 3D model and anchoring specs: CSB4008 on US Tornado Shelter.

About the CSB4008

CSB4008 – TORNADO SHELTER
8×40 Community Storm Shelter
2 Storm-Rated Access Doors
Occupancy: 64 – Maximum: 106

Tornado Shelter Standards
» Tornado Rated up to EF-5 Tornado
» Wind Load Resistance of 250 mph
» FEMA 320 / 361 & ICC500 Compliant
» IBC Structural Design Compliant
» Natural Air Ventilation
» Interior Bench Seating and LED Lighting

Compare mobile base (no concrete) sizes

ModelFootprintMaximum OccupancyDesign occupancyDoorsInstall type
CSB10088' x 10'Up to 26 persons16 persons1Mobile Base (No Concrete)
CSB101010' x 10'Up to 33 persons20 persons1Mobile Base (No Concrete)
CSB20088' x 20'Up to 53 persons32 persons1Mobile Base (No Concrete)
CSB201010' x 20'Up to 66 persons40 persons1Mobile Base (No Concrete)
CSB30088' x 30'Up to 80 persons48 persons2Mobile Base (No Concrete)
CSB301010' x 30'Up to 100 persons60 persons2Mobile Base (No Concrete)
CSB40088' x 40'Up to 106 persons64 persons2Mobile Base (No Concrete)
CSB50088' x 50'Up to 131 persons77 persons2Mobile Base (No Concrete)
CSB401010' x 40'Up to 133 persons80 persons2Mobile Base (No Concrete)
CSB501010' x 50'Up to 164 persons97 persons2Mobile Base (No Concrete)

Frequently asked questions

How many people does the CSB4008 hold?

The CSB4008 holds up to 106 persons Maximum Occupancy (3 sq ft per person), with a design occupancy of 64 persons (5 sq ft per person).

Is the CSB4008 a Concrete Slab Install or Mobile Base?

The CSB4008 is a Mobile Base (No Concrete), sitting on its own steel base with no concrete to pour. It's also available as a Concrete Slab Install (CS4008).

What size is the CSB4008 and how many doors does it have?

The CSB4008 measures 8' x 40' (320 sq ft of protected floor area) with 2 storm-rated access doors.
